NNV70125WE1A
- Certificates & Standards
- RoHs / TISI
| Type of Luminaire | Downlight |
|---|---|
| System DL | |
| Others (Simple) | |
| Set Model No. | NNV70125WE1A |
| Type of Luminaire | Downlight |
|---|---|
| System DL | |
| Others (Simple) | |
| Set Model No. | NNV70125WE1A |
| Type of Light Source | LED |
|---|---|
| Power Input | 11W |
| System Lumen Output | 900 lm |
| System Efficacy | 82 lm/W |
| Power Voltage | 220-240V |
| Power Factor | 0.95 |
| Lifetime | 50000H(L70) |
| CCT | 4000K |
| CRI | 80 |
| SDCM | <5 |
| Input Frequency | 50/60Hz |
| Dimming | non-Dimmable |
| Dimming Range | |
| UGR | |
| Glare Cut Angle | |
| Beam Angle | 24deg. |
| Rotation Angle | |
| Tilt Angle | |
| IP code | 20 |
| IK code | |
| Ambient Temperature Range | 5 - 35°C |
| Surge Protection | |
| Classification of Luminaries | Class Ⅱ |
| THDi | |
| Effective Projected Area | |
| Driver | External |
| Cut Out Size | |
| Dimensions | 130mm*130mm*85mm |
| Weight | 0.31 kg |
| Body | ADC(Black) |
| Reflector | Aluminium(Gray) |
| Diffuser | PC(Transparent) |
| Trim | Aluminium(White) |
| Caseing | |
| Country of Origin | China |
| Brand | Panasonic |
| Remarks | Cut Out Size : 110mm*110mm |
Spec and certification may change without notice.
